Specification Sheet

LOW
LEAD
COMPLIANT
2 Saddleback Cove
•
•
Glass Fillers
Architect/Engineering Specifications:
02/04/16
Ph 800-891-4808
Warranty:
Travelers Rest, SC 29690
by
5GF-W
Job Name__________________________________
•
NSF 61 - Section 9
NSF 372 (Low Lead Content)
Date______________________________________
•
ANSI A117.1 (ADA)•
Date:
Push Back Glass Filler
Product Compliance:
ASME A112.18.1 / CSA B125.1
www.tsbrass.com
•
•
equip Foodservice Accessories
Features & Benefits:
Fax [phone]
Model Specified________________Quantity_______
Variations Specified__________________________
One Year (Limited)
TAG:
by
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Flow Rate: 0.25 GPM min @ 60 psi•
2.50 GPM max @ 60 psi
Certified to ASME A112.18.1\CSA B125.1, NSF 61-Section 9 and NSF 372. Meets ADA ANSI\ICC A117.1 requirements.
Wall mount glass filler with polished chrome plated brass body, adjustable flow outlet, push back arm and 3/8" NPT male inlet.
Wall mount glass filler •
Adjustable screw flow•
Instantaneous shut-off•
3/8" NPT male inlet•
Material: Polished chrome plated brass body & pedestal, •
chrome plated metal flange and thermoplastic arm
4 1/8"
[105mm]
4 3/8"
[111mm]
1 1/8"
