Specification Sheet

Flow Rate: 1.07 GPM (4.1 Lpm) @ 60 PSI

Spray Force: 7.2 Ozf (204 Gramf)

3/4-14 UN

Male Inlet

Self-Closing

Cartridge

9 1/16"

231mm

5 1/2"

139mm

1 1/2"

38mm

Product Specifications:

Scale:

Model No.

Item No.

T&S BRASS AND BRONZE WORKS, INC.

02/02/15JRM

B-0107-J

Self-Closing Pre-Rinse Spray Valve w/ 1.07 GPM Spray Nozzle

2 Saddleback Cove / P.O. Box 1088

Travelers Rest, SC 29690

Date: 1:3

This Space for Architect/Engineer Approval

Job Name__________________________Date_________

Model Specified_____________________ Quantity______

Customer/Wholesaler______________________________

Contractor_______________________________________

Architect/Engineer_________________________________

Checked:

Drawn: Approved:

KJG

JHB

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com

Sheet: 1

Product Compliance:

ASME A112.18.1 / CSA B125.1

NSF 61 - Section 9

NSF 372 (Low Lead Content)

EPAct 2005 (PRSV)

EPA WaterSense (PRSV)

Hose Washer &

Hold Down Ring

(Included)

PAGE 1
Model No. T&S BRASS AND BRONZE WORKS, INC. 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 B-0107-J Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.
PAGE 2
Model No. T&S BRASS AND BRONZE WORKS, INC. B-0107-J 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com ITEM NO. 1 2 3 4 5 6 7 8 SALES NO. 003199-45 001120-45 002856-40 003198-45 010476-45 000907-45 018292-45 003128-25 DESCRIPTION Spray Valve Handle Screw Spray Valve Handle Spray Valve Bonnet Spray Valve Handle Nut #27 Washer Ring, Spray Valve Hold Down Shield, Low Flow 1.
