Specification Sheet

12 9/16"
319mm
357mm
14 1/16"
42 1/16"
1068mm
2 5/16"
58mm
1:9
Architect/Engineer_________________________________
Product Specifications:
Scale:
Model No.
05/26/16JRM
T&S BRASS AND BRONZE WORKS, INC.
Item No.
2 Saddleback Cove / P.O. Box 1088
44" Flexible Stainless Steel Hose, 1.42 GPM Spray Valve, 6" Wall
Travelers Rest, SC 29690
Quarter-Turn Eterna Cartridges w/ Spring Checks, Lever Handles,
Approved: 2
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
Date:
Bracket & Flexible Stainless Steel Supply Hoses
B-0113-B
EasyInstall Pre-Rinse Unit: Single Hole Deck Mount Mixing Faucet,
Checked:
Drawn:
JBC
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
EPAct 2005 (PRSV)
1.42 GPM
B-0107
Flange
[57mm]
Deck
Spray Valve
Hose w/ Spring & Spray Valve
44" Flexible Stainless Steel
Rough-In Requirement:
1 1/2" [38mm] Mounting Hole
Ø 2 1/4"
B-0109-01
6" Wall
Bracket
1 3/8"
35mm
Maximum
Thickness
Mounting Surface
for 1/2" NPSM Male)
(Remove Compression Nut
Compression Fittings
3/8" NPT x 24" Riser
Supply Hoses
Color Coded Indexes
For Clarity
Items Not Shown
18" Flexible
Lock Nut & Bushing
EasyInstall
for 5/8" O.D. Copper Tubing
Stainless Steel
Quarter-Turn
Eterna Cartridges w/
Spring Checks &
Lever Handles w/
Finger Hook
7 9/16"
192mm
