Specification Sheet

LOW
LEAD
COMPLIANT
12 5/8"
321mm
5 3/16"
131mm
357mm
14 1/16"
12 1/4"
311mm
41 7/8"
[1065mm]
F
•
•
•
Pre-Rinse Units
Architect/Engineering Specifications:
02/28/18
Fax 864-834-3518
Model Specified________________Quantity_______
Job Name__________________________________
• Flow Rate: 1.42 GPM @ 60 psi
• Ph 800-476-4103
• NSF 61 - Section 9
• ASME A112.18.1 / CSA B125.1
•
www.tsbrass.com
B-0123-CR-B
EPAct 2005 (PRSV)
•
T&S BRASS AND BRONZE WORKS, INC.
Job Name__________________________________
Date______________________________________
Model Specified________________Quantity_______
Variations Specified__________________________
TAG:
Pre-Rinse Units
Architect/Engineering Specifications:
02/28/18
Features & Benefits:
•
Ph 800-423-0150
•
Travelers Rest, SC 29690
Simi Valley, CA
•
Ph 800-476-4103 • Fax 864-834-3518
•
Simi Valley, CA
•
Ph 800-423-0150
Pre-Rinse Unit
Date:
Date______________________________________
Variations Specified__________________________
Pre-Rinse Unit
Date:
•
www.tsbrass.com
B-0123-CR-B
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove • Travelers Rest, SC 29690
NSF 372 (Low Lead Content)
Product Compliance:
•
• 2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140
Warranty:
Three Year (Limited)
Cerama Cartridge: Lifetime (Limited)
TAG:
1/2" NPT male inlets with Ø 2" adjustable flanges
Lever handles w/ color coded indexes
6” adjustable wall bracket
•
•
4-Arm
•
Optional Handles
4" Wrist Action
Lever (Standard)
Material: Polished chrome plated brass body, riser &
and overhead spring. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF 372. EPAct 2005 compliant.
B-0108 (1.07 GPM)
GPM spray valve, ceramic cartridges with check valves, lever handles, 1/2“ NPT female inlets, 6” adjustable wall bracket, spray valve holder
Adjustable centers from 7 3/4" to 8 1/4"
B-0107-J (1.07 GPM)
8” deck mount mixing faucet with polished chrome plated brass body, 24” riser, 44” flexible stainless steel hose, heat resistant handle, 1.42
plated metal handles and wall bracket
•
spray valve body, stainless steel hose, chrome
•
B-0108-C (0.65 GPM)
8” deck mount polished chrome plated brass body•
EasyInstall riser for quick installation•
44” flexible stainless steel hose w/ heat resistant gray •
handle and hold down ring
1.42 GPM spray valve •
Quarter-turn Cerama cartridges w/ check valves •
to prevent cross flow of water
Optional Pre-Rinse Spray Valves
B-0107 (1.42 GPM) (Standard)
B-0107-C (0.65 GPM)
Optional Cartridges With Checks
Quarter-Turn Cerama w/ Check Valve (Standard)
Quarter-Turn Eterna w/ Spring Check
