Specification Sheet

2 9/16"
66mm
14 1/16"
357mm
B-0108 (1.07 GPM)
B-0108-C (0.65 GPM)
B-0107 (1.42 GPM)
Material: Polished chrome plated riser, swivel arm &
B-0107-C (0.65 GPM)
spray valve body and stainless steel hose
B-0107-J (1.07 GPM)
Optional Pre-Rinse Spray Valves
24” riser
68” flexible stainless steel hose w/ heat resistant
gray handle and hold down ring
0.65 GPM angled spray valve
3/8” NPT pipe coupling connects to existing risers
Overhead swivel extension arm w/ adjustable
tension balancer
6” adjustable wall bracket
Overhead swivel extension arm retrofit kit with 24” riser, 68” flexible stainless steel hose with heat resistant handle, 0.65 GPM angled
spray valve, 3/8” NPT pipe coupling, Overhead swivel extension arm w/ adjustable tension balancer and 6” adjustable wall bracket.
Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF 372. EPAct 2005 compliant.
Variations Specified__________________________
Model Specified________________Quantity_______
Date______________________________________
Pre-Rinse Unit
Architect/Engineering Specifications:
02/28/18
One Year (Limited)
Job Name__________________________________
Flow Rate: 0.65 GPM @ 60 psi
Ph 800-476-4103
NSF 61 - Section 9
Ph 800-423-0150
Travelers Rest, SC 29690
Simi Valley, CA
Fax 864-834-3518
Pre-Rinse Units
Date:
ASME A112.18.1 / CSA B125.1
Product Compliance:
www.tsbrass.com
B-0126-R
T&S BRASS AND BRONZE WORKS, INC.
EPAct 2005 (PRSV)
Features & Benefits:
NSF 372 (Low Lead Content)
2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi
Temperature: 40
F - 140 F
Warranty:
TAG:
28 9/16"
726mm
