Specification Sheet

LOW
LEAD
COMPLIANT
12 3/4"
324mm
2 3/8"
61mm
306mm
12 1/16"
3 15/16"
100mm
59mm
2 5/16"
34 1/8"
867mm
12 5/8"
321mm
8 7/8"
226mm
12"
305mm
3 11/16"
94mm
12 1/16"
306mm
Variations Specified__________________________
Model Specified________________Quantity_______
Date______________________________________
Pre-Rinse Unit
Architect/Engineering Specifications:
02/28/18
Three Year (Limited)
Job Name__________________________________
Add-On Faucet: 9.73 GPM @ 60 psi
Spray Valve: 0.65 GPM @ 60 psi
Travelers Rest, SC 29690
•
• EPAct 2005 (PRSV)
• NSF 372 (Low Lead Content)
Ph 800-423-0150
•
2 Saddleback Cove
Simi Valley, CA
•
•
Fax [phone]• Ph 800-476-4103
Pre-Rinse Units
Date:
• NSF 61 - Section 9
Features & Benefits:
www.tsbrass.com
B-0131-ADF12-BC
T&S BRASS AND BRONZE WORKS, INC.
•
Product Compliance:
ASME A112.18.1 / CSA B125.1
EPA WaterSense (PRSV)
•
•
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Flow Rate: •
Warranty:
TAG:
4" Wrist Action
Lever (Standard)
6” adjustable wall bracket
•
B-0107-C (0.65 GPM)
•
B-0199-06
1.5
Material: Polished chrome plated brass body, tubular
nozzle, add-on faucet body, riser, overhead swivel
Optional Add-On Faucet Outlets (Series 1 / VR Series 6)
chrome plated metal handles
•
arm & spray valve body, stainless steel hose and
B-0199-06-F10
B-0199-06-WS
B-0107-J (1.07 GPM)
(Standard)
B-0108 (1.07 GPM)
1.0
2.2
Optional Pre-Rinse Spray Valves
Quarter-Turn Eterna w/ Spring Check (Standard)
Quarter-Turn Cerama w/ Check Valve
4-Arm
B-0108-C (0.65 GPM)
B-0107 (1.42 GPM)
VR Aerated
GPM
Optional Handles
8” wall mount mixing faucet with polished chrome plated brass body, add-on faucet with compression cartridge and lever handle, 12” swing
nozzle with stream regulator outlet, 26” riser, overhead swivel arm, 20” flexible stainless steel hose with heat resistant handle, 0.65 GPM low
Optional Cartridges With Checks
flow spray valve, compression cartridges with spring checks, lever handles, 1/2“ NPT female inlets, 6” adjustable wall bracket and spray valve
holder. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 & NSF 372. EPAct 2005 compliant.
8” wall mount polished chrome plated brass body•
EasyInstall add-on faucet w/ polished chrome plated•
brass body
12” swing nozzle w/ stream regulator outlet, Series 1•
20” flexible stainless steel hose w/ heat resistant gray •
handle and hold down ring
0.65 GPM low flow spray valve •
Quarter-turn Eterna compression cartridges w/ spring •
checks to prevent cross flow of water
Lever handles w/ color coded indexes•
1/2" NPT female eccentric inlets with Ø 2" flanges •
Adjustable centers from 7 3/4" to 8 1/4"
Aerated
B-0199-01-F10
B-0199-01-WS
B-0199-01
