Specification Sheet

9 9/16"
244mm
14"
356mm
101mm
4"
374mm
14 11/16"
37 5/8"
956mm
4 7/16"
112mm
2 5/16"
59mm
Outlet
Nozzle
Regulator
EasyInstall
18" Riser
Indexes
Finger Hook
3/8" NPT x
w/ Stream
063X
w/ Color Coded
14" Swing
& Bushing
Lock Nut
Quarter-Turn
Eterna Cartridges
w/ Spring Checks
& Lever Handles
Items Not Shown
For Clarity
3 11/16"
94mm
8"
203mm
12 3/4"
323mm
Rough-In Requirement:
(2)
1" [25mm] Mounting Holes
2
Pre-Rinse Unit: EasyInstall 8" Wall Mount Mixing Faucet, Quarter-Turn Eterna
__________________________Date_________
Product Specifications:
Scale:
T&S BRASS AND BRONZE WORKS, INC.
02/17/17
Item No.
Model No.
B-0133-01
2 Saddleback Cove / P.O. Box 1088
Cartridges w/ Spring Checks, Lever Handles, Add-On Faucet, 14" Swing
Customer/Wholesaler______________________________
Nozzle, 56" Flexible Stainless Steel Hose, 1.42 GPM Spray Valve, 9" Wall
Travelers Rest, SC 29690
Contractor_______________________________________
JRM
Model Specified_____________________ Quantity______
Drawn:
of
1
Bracket & 1/2" NPT Male Inlets
1:8
Architect/Engineer_________________________________
Checked:
Approved:
DMH
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
Sheet:
Date:
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
EPAct 2005 (PRSV)
& Lever
Handle
B-0109-02
Cartridge
1/2" NPT
Male Inlets
B-0107
Bracket
9" Wall
Spray Valve
1.42 GPM
EasyInstall
Add-On
Faucet
w/ Quarter-
Turn Eterna
56" Flexible Stainless
Steel Hose w/ Spring
& Spray Valve
Maximum
5mm
Thickness
3/16"
2"
51mm
Mounting
Surface
12 5/8"
321mm
