Specification Sheet

7 1/4"
184mm
5"
127mm
92mm
3 5/8"
2 5/16"
59mm
Notes:
The Add-On Faucet is an Addition to Pre-Rinse 1.
Units and is Installed in Outlets of Base Mixing
Faucets of Units Before Fitting Riser Pipes
4-Arm Handle Controls Water On-Off Thru 2.
Washdown Hose Only. Pressure is Always
"On" in the Riser Pipe (Controlled by Base
Mixing Faucet)
Contractor_______________________________________
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
11/10/17KJG
Washdown Hose Unit, Quarter-Turn Eterna Cartridge w/ Spring Check,
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
4-Arm Handle, 68" Flexible Stainless Steel Hose, 0.65 GPM Low Flow Angled
Travelers Rest, SC 29690
Date:
Spray Valve & Finger Hook
B-0165-C35-GGB
2 Saddleback Cove / P.O. Box 1088
2
of
1Sheet:
1:6
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
DMH
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
EPAct 2005 (PRSV)
Pre-Rinse Riser
(Sold Separately)
3/8" NPT
Female
Outlet
Conversion Kit, EZ-K
4-Arm Handle
68" Flexible Stainless
Eterna Cartridge w/
Steel Hose
Spring Check &
Swivel Adapter
034A
(Sold Separately).
Finger Hook
to Fit T&S Standard
Swivel Outlets with
3/8" NPT Male Inlet.
Converts to EasyInstall
Quarter-Turn
B-0107-C35
0.65 GPM Low Flow
Angled Spray Valve
7 1/4"
184mm
