Specification Sheet

16mm
Maximum
Thickness
203mm
8"
5/8"
5 1/8"
130mm
12"
305mm
6 13/16"
173mm
12 5/8"
321mm
Adjustable From
Quarter-Turn Cerama
Cartridges w/
Spring Checks &
Swivel Joint
Lever Handles w/
[197mm to 210mm]
7 3/4" to 8 1/4"
Color Coded Indexes
12" Swing Nozzle w/
B-0199-01-F10
1.0 GPM Aerator.
Rigid Conversion Requires
014200-45 Lock Washer
(Included)
B-0425
Supply Nipple Kit
w/ 1/2" NPT
Male Inlets
Mounting Surface
Contractor_______________________________________
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
11/01/17JRM
2
8" Deck Mount Mixing Faucet, Quarter-Turn Cerama Cartridges w/ Check
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
Valves, Lever Handles, 12" Swing Nozzle w/ 1.0 GPM Aerator & 1/2" NPT
Travelers Rest, SC 29690
Date:
Male Supply Nipples
B-0221-CR-K-F10
2 Saddleback Cove / P.O. Box 1088
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
1:6
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
MRC
JHB
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Rough-In Requirement:
(2)
1" [25mm] Mounting Holes
