Specification Sheet

ManualsBrandsT and S Brass ManualsfaucetsT and S Brass B-200 Wall Mounted Double Pantry Faucet with 8" Centers, 18" Swing Nozzle, Stream Regulator Outlet and Lever Handles

3 11/16"

93mm

2 3/8"

61mm

18"

458mm

6 7/16"

163mm

12 5/8"

321mm

Adjustable from

7 3/4" to 8 1/4"

[197mm to 210mm]

__________________________Date_________

Product Specifications:

Scale:

Model No.

Item No.

T&S BRASS AND BRONZE WORKS, INC.

02/17/17JRM

B-0230

Model Specified_____________________ Quantity______

Handles, 18" Swivel Nozzle & 1/2" NPT Female Inlets

8" Wall Mount Mixing Faucet, Quarter-Turn Eterna Cartridges, Lever

Travelers Rest, SC 29690

Date: 1:6

2 Saddleback Cove / P.O. Box 1088

Customer/Wholesaler______________________________

Contractor_______________________________________

Architect/Engineer_________________________________

Checked:

Drawn: Approved:

MRC

JHB

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com

Sheet:

This Space for Architect/Engineer Approval

Job Name

Product Compliance:

ASME A112.18.1 / CSA B125.1

NSF 61 - Section 9

NSF 372 (Low Lead Content)

ANSI A117.1 (ADA)

Ø 2" [51mm]

Flanges w/

1/2" NPT

Female Inlets

Lever Handles w/

Color Coded Indexes

Quarter-Turn Eterna

Cartridges w/

Spring Checks &

203mm

Mounting

Surface

9 9/16"

242mm

065X

18" Swing Nozzle w/

Stream Regulator

Outlet

Summary of content (2 pages)

PAGE 1
Model No. T&S BRASS AND BRONZE WORKS, INC. 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 B-0230 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.
PAGE 2
Model No. T&S BRASS AND BRONZE WORKS, INC. B-0230 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com 2 ITEM NO. 1 2 3 4 5 6 7 8 B-PT 065X 009538-45 011429-45 001074-45 014200-45 018506-19NS 000925-45 9 002711-40NS 10 012442-40NS 11 12 001019-45 00AA 13 012443-40NS 14 001638-45NS 15 002712-40NS 16 001193-19NS SALES NO.
