Specification Sheet

4 13/16"
122mm
2 5/8"
67mm
305mm
12"
7 9/16"
191mm
8"
203mm
Stream Regulator Outlet
Mounting Surface
12" Swing Nozzle w/
062X
Built-In
Integral Stop
Contractor_______________________________________
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
03/17/14JRM
B-0231-BST
Model Specified_____________________ Quantity______
8" Wall Mount Mixing Faucet, Eterna Cartridges, Lever Handles,
Travelers Rest, SC 29690
Date:
12" Swing Nozzle, Built-In Stops & 1/2" NPT Female Inlets
Customer/Wholesaler______________________________
2 Saddleback Cove / P.O. Box 1088
2
of
1Sheet:
1:4
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
DHL
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
7 3/4" to 8 1/4"
[197mm to 210mm]
Lever Handles w/
Color Coded Indexes
Eterna Cartridges &
Adjustable From
Female Inlets
Ø 2" [51mm]
Flanges w/
1/2" NPT
Swivel Joint
3 13/16"
98mm
12 7/16"
315mm
