Specification Sheet

12 5/8"
321mm
12"
305mm
191mm
7 1/2"
61mm
2 3/8"
4 3/8"
111mm
203mm
8"
3 11/16"
93mm
B-0418
Supply Stops
1/2" NPT Male Inlet
8" Wall Mount Mixing Faucet, Quarter-Turn Eterna Cartridges w/ Spring
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
01/22/18JRM
2
Checks, Lever Handles, 12" Swing Nozzle w/ 2.2 VR Aerator, 1/2" NPT Male
2 Saddleback Cove / P.O. Box 1088
Contractor_______________________________________
Customer/Wholesaler______________________________
Inlets, Short Elbow Installation Kit, Supply Stops and 36" Flexible Stainess
Travelers Rest, SC 29690
Date:
Steel Hoses
Model Specified_____________________ Quantity______
B-0233
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
1:6
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
MRC
JHB
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
12" Swing Nozzle w/
B-0199-06
VR 2.2 GPM Aerator
Converts to Rigid w/
014200-45
Lock Washer (Included).
013121-45
36" Flexible Supply Hose w/
1/2" NPT Male x 1/2" NPSM Female
Mounting Surface
B-0230-K
1/2" NPT Male
Short Elbow
Installation Kit
1/16"
2mm
Maximum
Thickness
Adjustable from
7 3/4" to 8 1/4"
[197mm to 210mm]
Quarter-Turn Eterna Cartridges
Female Inlets
Color Coded Indexes
Lever Handles w/
w/ Spring Checks &
Ø 2" [51mm]
Flanges w/
1/2" NPT
Swivel Joint
