Specification Sheet

ManualsBrandsT and S Brass ManualsfaucetsT and S Brass 9.8 GPM Deck Mounted Bridge Utility Faucet - Includes Wrist Blade Handles and 5-3/4" Gooseneck Spout
12
102mm
4"
6 1/4"
159mm
12"
305mm
13 3/16"
335mm
145mm
5 3/4"
8 7/16"
215mm
Contractor_______________________________________
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
11/01/17JRM
B-0325-CC-CR-W4
4" Deck Mount Mixing Faucet w/ Quarter-Turn Cerama Cartridges w/
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
Check Valves, 4" Wrist Action Handles, 5 3/4" Swivel/Rigid Gooseneck w/
Travelers Rest, SC 29690
Date:
Stream Regulator Outlet & 1/2" NPT Male Inlets
2 Saddleback Cove / P.O. Box 1088
2
of
1Sheet:
1:4
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
MRC
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Rough-In Requirement:
(2)
1" [25mm] Mounting Holes
[33mm]
Hex
1 5/16"
Quarter-Turn
Cerama Cartridges w/
Check Valves &
4" Wrist Action Handles
w/ Color Coded Indexes
Mounting Surface
133X
Swivel Gooseneck w/
Stream Regulator Outlet.
Rigid Conversion Requires
014200-45 Lock Washer
(Included)
1/2" NPT
Male Inlets
