Specification Sheet

ManualsBrandsT and S Brass ManualsfaucetsT and S Brass 0.5 GPM Deck Mounted Bridge Utility Faucet - Includes Wrist Blade Handles and 5-3/4" Gooseneck Spout

6 11/16"

170mm

102mm

8 7/8"

225mm

5 3/4"

145mm

13 5/16"

338mm

12"

305mm

Swivel Joint

4" Wrist Action Handles

Check Valves &

Quarter-Turn

Cerama Cartridges w/

w/ Color Coded Indexes

5 3/4" Swivel/Rigid

Gooseneck w/

B-0199-06-N05

VR 0.5 GPM Non-Aerated

Spray Device Outlet.

Rigid Conversion Requires

014200-45 Lock Washer

(Included)

__________________________Date_________

Product Specifications:

Scale:

Model No.

Item No.

T&S BRASS AND BRONZE WORKS, INC.

11/01/17JRM

B-0328-CR-VF05

Model Specified_____________________ Quantity______

Customer/Wholesaler______________________________

0.5 GPM Non-Aerated VR Outlet Device & 1/2" NPT Female Inlets

Check Valves, Wrist Action Handles, 5 3/4" Swivel/Rigid Gooseneck w/

Travelers Rest, SC 29690

Date: 1:4

2 Saddleback Cove / P.O. Box 1088

4" Deck Mount Mixing Faucet, Quarter-Turn Cerama Cartridges w/

Contractor_______________________________________

Architect/Engineer_________________________________

Checked:

Drawn: Approved:

MRC

JHB

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com

Sheet:

This Space for Architect/Engineer Approval

Job Name

Product Compliance:

ASME A112.18.1 / CSA B125.1

NSF 61 - Section 9

NSF 372 (Low Lead Content)

ANSI A117.1 (ADA)

Adjustable from

3 3/4" to 4 1/4"

[95mm to 108mm]

Mounting Surface

Ø 2" [51mm]

Flanges w/

1/2" NPT

Female Inlets

Summary of content (2 pages)

PAGE 1
Model No. T&S BRASS AND BRONZE WORKS, INC. 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 B-0328-CR-VF05 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.
PAGE 2
Model No. T&S BRASS AND BRONZE WORKS, INC. B-0328-CR-VF05 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com ITEM NO. SALES NO. 1 B-0199-06-N05 2 3 4 009538-45 011429-45 001074-45 5 6 7 001193-19NS 018506-19NS 000925-45 8 B-WH4C-NS 9 B-WH4-NS 10 012395-25NS 11 001019-45 2 12 00AA 3 13 012394-25NS 14 B-WH4H-NS 15 014200-45 1 4 DESCRIPTION 0.
