Specification Sheet

10 13/16"
274mm
172mm
6 3/4"
5 11/16"
145mm
Mounting Surface
2 3/4"
69mm
2
__________________________Date_________
Product Specifications:
Scale:
Model No.
07/23/16JRM
B-0346
T&S BRASS AND BRONZE WORKS, INC.
Model Specified_____________________ Quantity______
3 3/8" Wall Mount Mixing Faucet, Eterna Cartridges, Lever Handles, Swivel
Travelers Rest, SC 29690
Date:
Gooseneck w/ Stream Regulator Outlet & 1/2" NPT Female Inlets
Item No.
Contractor_______________________________________
Customer/Wholesaler______________________________
Approved:
of
1
2 Saddleback Cove / P.O. Box 1088
Architect/Engineer_________________________________
Checked:
Drawn:
JBC
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
Sheet:
1:4
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
[95mm to 108mm]
3 1/8" to 3 5/8"
Eterna Cartridges &
Adjustable
from
Lever Handles w/
Color Coded Indexes
2"
[51mm]
Flanges w/
1/2" NPT
Female Inlets
133X
Swivel Gooseneck w/
Stream Regulator Outlet
9 1/8"
232mm
