Specification Sheet

ManualsBrandsT and S Brass ManualsPlumbing5-5/16 in. Gooseneck Clearance

130mm

5 1/8"

5 9/16"

141mm

Rigid Gooseneck w/

B-0199-02

2.2 GPM Aerator

1 7/8"

47mm

(Included)

150A

for 1/4" NPT Connection

Optional Tailpiece & Nut

1 11/16"

[43mm]

Rigid Deck Flange

w/ 1/2" NPSM Male Inlet

Mounting Surface

10 5/8"

270mm

1 1/8"

29mm

Maximum

Thickness

Rough-In Requirement:

1" [25mm] Mounting Hole

Model Specified_____________________ Quantity______

Product Specifications:

Scale:

Model No.

Item No.

T&S BRASS AND BRONZE WORKS, INC.

02/29/16JRM

B-0521

2 Saddleback Cove / P.O. Box 1088

Contractor_______________________________________

Customer/Wholesaler______________________________

Travelers Rest, SC 29690

Rigid Deck Mount Dummy 6" Gooseneck w/ 2.2 GPM Aerator

1Sheet:

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com

JHB

DHL

Date: 1:4

Architect/Engineer_________________________________

Checked:

Drawn: Approved:

This Space for Architect/Engineer Approval

Job Name

__________________________Date_________

Product Compliance:

ASME A112.18.1 / CSA B125.1

NSF 61 - Section 9

NSF 372 (Low Lead Content)

Summary of content (2 pages)

PAGE 1
Model No. T&S BRASS AND BRONZE WORKS, INC. 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 B-0521 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.
PAGE 2
Model No. T&S BRASS AND BRONZE WORKS, INC. B-0521 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com ITEM NO. 1 2 3 SALES NO. B-0199-02 B-0199-01 044A 2.2 GPM Aerator, 3/8" NPSM Male 2.
