Specification Sheet

6 5/8"
169mm
5 11/16"
144mm
1
of
2
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
Travelers Rest, SC 29690
02/24/12
KJG
Sheet:
Deck Mount Dummy Swivel Gooseneck w/ Plain End Outlet,
1.5 GPM Flow Control and Lock Washer for Rigid Option
2 Saddleback Cove / P.O. Box 1088
B-0545-F15-LW
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
DMH
Approved
Drawn
Checked
Date:
1:3
Architect/Engineer_________________________________
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
150A
Tailpiece & Nut
furnished for
optional 1/4"
NPT connection.
44mm
1 3/4"
10 5/8"
270mm
Nut installed.
1/2" NPSM Male
Thread Inlet w/o
150A Tailpiece &
Swivel Gooseneck
w/ Plain End.
Converts to rigid with
furnished 014200-45
lock washer
47mm
1 7/8"
1 1/8" Max.
[29mm]
Rough-in Requirement:
1" [25mm] Hole
