Specification Sheet

ITEM
NO.
SALES NO. DESCRIPTION
1 133XP Swivel Gooseneck, Plain End
2 009538-45 Swivel Washer
3 011429-45 Swivel Sleeves (2)
4 001074-45 O-Ring
5 014200-45 Star Washer, Anti-Rotation
6 000999-45 Brass Lock Washer
7 002954-45 Shank Lock Nut
8 150A 1/4" NPT Tailpiece & Nut
2Sheet:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
B-0545-F15-LW
2 Saddleback Cove / P.O. Box 1088
Approved
Drawn
Checked
NTS
of
Date:
1.5 GPM Flow Control and Lock Washer for Rigid Option
KJG
02/24/12
Scale:
Product Specifications:
DMH JHB
2
Deck Mount Dummy Swivel Gooseneck w/ Plain End Outlet,
5
6
7
1
2
3
4
8
