Specification Sheet
14 3/4"
374mm
305mm
12"
11 9/16"
294mm
•
(2) 1/2" NPT female inlet supply stops
Material: Polished chrome plated brass, chrome plated
4" Wrist Action
metal handles and stainless steel hose
•
NPSM / 5/8" O.D. compression connection, (2) 36" flexible stainless steel supply hoses, (2) 1/2" NPT female inlet supply stops and wall hook.
Optional Handles
Single hole deck mount mixing faucet with polished chrome plated brass body, add-on faucet with compression cartridge with check and lever
spray valve with hook nozzle, compression cartridges with spring checks, lever handles, 18" flexible stainless steel supply hoses with 1/2"
Certified to ASME A112.18.1/CSA B125.1, NSF 61, Section 9, NSF 372 and ASSE 1001
1/2" NPSM female connectors
handle, 12" swing nozzle with stream regulator outlet, 3/8" NPT swivel vacuum breaker above add-on faucet, 60" flexible stainless steel hose,
Lever (Standard)
4-Arm
Single deck mount w/ plished chrome plated brass body•
EasyInstall add-on faucet for quick installation w/•
polished chrome plated brass body
3/8" NPT vacuum breaker•
60” flexible stainless steel hose w/ heat resistant gray•
handle and hold down ring
Spray valve with hook nozzle •
12" swing nozzle•
Quarter-turn Eterna compression cartridge w/ spring•
checks to prevent cross flow of water
Lever handles with color coded indexes•
18" flexibles stainless steel supply hoses with•
1/2" NPSM / 5/8" O.D. compression connection
(2) 36" flexible stainless steel supply hoses w/ 1/2" NPT x •
Optional Cartridges With Checks
Quarter-Turn Cerama w/ Check Valve
Quarter-Turn Eterna w/ Spring Check (Standard)
Variations Specified__________________________
One Year (Limited)
Faucet and Spray Valve Assemblies
Spray Unit with Mixing Control Valve
Architect/Engineering Specifications:
05/05/17
Model Specified________________Quantity_______
Job Name__________________________________
Add-On Faucet: 5.57 GPM @ 60psi
Spray Valve: 4.80 GPM @ 60 psi
Travelers Rest, SC 29690
•
• NSF 372 (Low Lead Content)
2 Saddleback Cove
Simi Valley, CA
•
•
Fax 864-834-3518• Ph 800-476-4103
Date______________________________________
Date:
• NSF 61 - Section 9
• ASME A112.18.1 / CSA B125.1
Features & Benefits:
www.tsbrass.com
B-0602
T&S BRASS AND BRONZE WORKS, INC.
•
Ph 800-423-0150
•
ASSE 1001 (VB)
Product Compliance:
•
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Flow Rate: •
Warranty:
TAG:
