Specification Sheet

27mm
1 1/16"
3 7/8"
98mm
9 3/16"
233mm
Male Outlet
Pail Hook Spout
w/ Garden Hose
Mounting Surface
78mm
3 1/16"
2 3/8"
61mm
Inlets Adjustable
from 2 1/4" to 8 1/4"
[57mm to 210mm]
Below or Above Centerline
__________________________Date_________
Handles, Pail Hook Spout w/ Garden Hose Male Outlet, Polished Chrome
Job Name
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
01/18/16
B-0669-01
2 Saddleback Cove / P.O. Box 1088
of
2
Contractor_______________________________________
Model Specified_____________________ Quantity______
Finish, 1/2" NPT Vacuum Breaker & 1/2" NPT Female Adjustable Inlets w/
Travelers Rest, SC 29690
Customer/Wholesaler______________________________
Wall Mount Service Sink Faucet, Eterna Cartridges w/ Spring Checks, Lever
JRM
Built-In Service Stops
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
Date: 1:4
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
DHL
JHB
This Space for Architect/Engineer Approval
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
ASSE 1001 (VB)
Eterna Cartridges w/
Finish on Faucet
Body & Spout
Color Coded Indexes
Polished Chrome
Built-In Service
Stops
B-0969
1/2" NPT Vacuum
Lever Handles w/
Spring Checks &
Breaker
Ø 2" [51mm]
Flanges w/
1/2" NPT
Female Inlets
