Specification Sheet

3 5/8"
92mm
12 7/16"
315mm
61mm
2 3/8"
101mm
4"
4 13/16"
122mm
1 3/16"
31mm
Quarter-Turn
Breaker
Color Coded Indexes
B-0969
1/2" NPT Vacuum
Cerama Cartridges
w/ Check Valves &
Lever Handles w/
2" [51mm]
Flanges w/
1/2" NPT Female
Inlets
8"
203mm
Adjustable from
7 3/4" to 8 1/4"
[197mm to 210mm]
Garden Hose
Male Outlet
8" Wall Mount Service Sink Faucet w/ Quarter-Turn Cerama Cartridges
Job Name
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
10/24/16JRM
2 Saddleback Cove / P.O. Box 1088
Contractor_______________________________________
Customer/Wholesaler______________________________
__________________________Date_________
w/ Check Valves, Lever Handles, Garden Hose Male Outlet, 1/2" NPT
Travelers Rest, SC 29690
Model Specified_____________________ Quantity______
B-0674-CR-POL
2
Female Inlets & Polished Chrome Finish
of
1Sheet:
Date: 1:4
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
JBC
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
This Space for Architect/Engineer Approval
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
ASSE 1001 (VB)
