Specification Sheet

LOW
LEAD
COMPLIANT
3 1/2"
89mm
Maximum
8"
203mm
57mm
2 1/4"
101mm
Minimum
4"
4 15/16"
126mm
vacuum breaker & wall hook and polished chrome plated metal
4-Arm (Standard)
8” concealed bypass mixing valve with brass body and polished chrome plated brass adjustable wall flanges and sleeves, polished chrome
plated spout with garden hose male outlet, compression cartridges with spring checks, 4-arm handles, 1/2” NPT female loose key straight
Lever
4" Wrist Action
handles
1/2” NPT atmospheric vacuum breaker wall hook
nozzle. Certified to ASME A112.18.1/CSA B125.1, NSF 61-section 9, NSF 372 and ASSE 1001.
•
stop inlets with tee handles, atmospheric vacuum breaker, wall hook, 68” reinforced PVC hose with spray valve and extended spray
Material: Brass body, polished chrome plated brass adjustable flanges,
• 68” reinforced PVC hose with spray valve and extended spray nozzle
•
8” concealed bypass mixing valve w/ 1/2” NPT female union inlet •
connections
6” tall polished chrome plated brass adjustable wall flanges & sleeves•
Polished chrome plated spout w/ garden hose male outlet •
Quarter-turn Eterna compression cartridges w/ spring checks•
to prevent cross flow of water
4-arm handles w/ color coded indexes•
1/2” NPT female loose key straight stop inlets w/ tee handles•
Optional Handles
Optional Cartridges With Checks
Quarter-Turn Cerama w/ Check Valve
Quarter-Turn Eterna w/ Spring Check (Standard)
•
F
•
Medical Bedpan Washers
Bedpan Washer
Architect/Engineering Specifications:
ASME A112.18.1 / CSA B125.1•
Flow Rate: 4.86 GPM @ 60 psi •
Ph 800-476-4103 •
NSF 61 - Section 9•
Features & Benefits:
•
NSF 372 (Low Lead Content)
Product Compliance:
•
Job Name__________________________________
Model Specified________________Quantity_______
Fax [phone]
11/22/17
•
Date______________________________________
Variations Specified__________________________
•
Ph 800-423-0150
•
www.tsbrass.com
B-0682-ST
•
T&S BRASS AND BRONZE WORKS, INC.
ASSE 1001 (VB)
Simi Valley, CA
Date:
Travelers Rest, SC 29690 • 2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140
Warranty:
One Year (Limited)
PVC Hose: Two year (Limited)
TAG:
