Specification Sheet

1 5/8"
42mm
3 5/8"
93mm
Loose Key
Stop
Garden Hose
Male Outlet
1:2
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
08/24/16JRM
2 Saddleback Cove / P.O. Box 1088
Single Hole, Single Temperature, Wall Mount Sill Faucet, Loose Key Stop,
Garden Hose Male Outlet, Compression Cartridge and 1/2" NPT Female
Travelers Rest, SC 29690
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
JHB
JBC
Approved:Drawn:
Checked: Date:
Inlet
B-0731
of
2
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
2" [51mm]
Flange w/
3/4" NPT
Female Inlet
