Specification Sheet

3 7/8"
99mm
Mounting Surface
Rosespray
Screw
Outlet
Vandal
Resistant
6 3/4"
171mm
Metering Cartridge
(Requires 3/32" Hex
Key for Adjustment)
Pivot Action
2"
[51mm]
Flange w/
1/2" NPT
Female Inlet
Contractor_______________________________________
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
02/16/15GEF
B-0800-PA
Model Specified_____________________ Quantity______
Wash Sink Metering Faucet with Pivot Action Metering Cartridge,1/2" NPT
Travelers Rest, SC 29690
Date:
Female Inlet and Ø 1 1/4" Rosespray Outlet
Customer/Wholesaler______________________________
2 Saddleback Cove / P.O. Box 1088
2
of
1Sheet:
1:8
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
DHL
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Blank Pivot Action Handle
w/ Vandal Resistant
Screw & Spanner Bit
(Included)
