Specification Sheet

LOW
LEAD
COMPLIANT
5 7/8"
149mm
47mm
1 7/8"
246mm
9 11/16"
145mm
5 3/4"
98mm
3 7/8"
3 7/16"
87mm
2 11/16"
68mm
N/A
N/A
B-0199-07-F10
VR Aerated
B-0199-07-WS
B-0199-07
Non-Aerated
B-0199-02-N035
(Laminar)
B-0199-02-N05
N/A
spout & chrome plated metal caps
• Material: polished chrome plated brass body, tubular
Section 9 and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
cartridges, push button caps, and 1/2" NPSM male inlets with coupling nuts. Certified to ASME A112.18.1/CSA B125.1, NSF 61-
•
4" centerset deck mount mixing faucet with polished chrome plated brass cast body, rigid gooseneck, 2.2 GPM aerator, metering
Push button (hot & cold) caps w/ vandal resistant screw
•
•
1/2" NPSM male inlets with coupling nuts
Wrist Action Metering
Optional Outlets (Series 2 / VR Series 7)
Pivot Action Metering
Push Button Metering (Standard)
2.2
1.5
1.0
0.5
Optional Cartridges
0.35
Adjustable metering cycle, 10 to 30 seconds
GPM
Standard
B-0199-02-WS
Aerated
B-0199-02-F10
•
N/A
N/A
N/A
N/A
4" centerset deck mount mixing faucet with polished •
chrome plated brass cast body
Rigid gooseneck •
2.2 GPM aerator, Series 2 (B-0199-02)•
Metering cartridges
VR Non-Aerated
(VR Laminar)
B-0199-07-N035
B-0199-07-N05
N/A
N/A
N/A
One Year (Limited)
Variations Specified__________________________
Slow Self-Closing Metering Faucet
Architect/Engineering Specifications:
08/04/17
Date:
Medical and Lavatory Faucets
Date______________________________________
Job Name__________________________________
Model Specified________________Quantity_______
•
@ 15 sec = .55 gal
2 Saddleback Cove
•
• ANSI A117.1 (ADA)
• NSF 372 (Low Lead Content)
• NSF 61 - Section 9
• ASME A112.18.1 / CSA B125.1
Product Compliance:
Travelers Rest, SC 29690
Ph 800-476-4103
• Fax [phone]
www.tsbrass.com
B-0834
T&S BRASS AND BRONZE WORKS, INC.
Features & Benefits:
•
Ph 800-423-0150
•
•
Simi Valley, CA
•
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Flow Rate: 2.2 GPM @ 60 psi •
Water Consumption: @ 10 sec = .37 gal
Warranty:
TAG:
