Specification Sheet

ManualsBrandsT and S Brass ManualsfaucetsT and S Brass Deck Mounted Medical Faucet with Cast Basin Spout, 2.2 GPM VR Aerator and 4" Wrist Action Handles with VR Screws
12
4"
102mm
5 7/8"
149mm
1 7/16"
36mm
3 3/4"
96mm
1 7/8"
48mm
2 5/8"
67mm
12"
305mm
4 5/16"
110mm
Coupling Nuts
w/ 1/2" NPSM
Male Shanks
Eterna Cartridge & 4" Wrist
& Color Coded Indexes
Action Handles w/ VR Screws
1/2" NPSM
B-0199-08
Vandal Resistant
2.2 GPM Aerator
126mm
4 15/16"
3/4"
19mm
Maximum
Thickness
Rough-In Requirement:
(2)
1 1/8" [29mm] Mounting Holes
Architect/Engineer_________________________________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
04/25/15JRM
B-0890-VRS
1:4
2 Saddleback Cove / P.O. Box 1088
Action Handles w/ Vandal Resistant Screws, Vandal Resistant
Travelers Rest, SC 29690
2
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
JHB
JBC
Approved:
Date:
2.2 GPM Aerator & 1/2" NPSM Male Inlet Shanks
4" Centerset Mixing Faucet, Eterna Cartridges, 4" Wrist
Checked:
Drawn:
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Mounting
Surface
