Specification Sheet

LOW
LEAD
COMPLIANT
142mm
5 9/16"
183mm
7 1/4"
10 7/8"
277mm
4 3/8"
112mm
3/4"
19mm
Maximun
Thickness
149mm
5 7/8"
128mm
5 1/16"
12"
305mm
Model Specified________________Quantity_______
Variations Specified__________________________
Flow Rate: 0.5 GPM @ 60 psi
Job Name__________________________________
Date______________________________________
Architect/Engineering Specifications:
One Year (Limited)
•
Ph 800-476-4103
•
NSF 61 - Section 9•
•
•
Features & Benefits:
•
NSF 372 (Low Lead Content)
Product Compliance:
•
ASME A112.18.1 / CSA B125.1•
Medical and Lavatory Faucets
11/16/15
Fax [phone]
Centerset Lavatory Faucet
Travelers Rest, SC 29690
Date:
Ph 800-423-0150
•
www.tsbrass.com
B-0892-QT-VF05
•
T&S BRASS AND BRONZE WORKS, INC.
ANSI A117.1 (ADA)
Simi Valley, CA
• 2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Warranty:
TAG:
VR Non-Aerated
B-0199-06-WS
VR Aerated
B-0199-21-VRF
B-0199-06-F10
Eterna
Quarter-Turn Eterna (Standard)
Optional Cartridges
Quarter-Turn Cerama
• Material: Chrome plated brass body and tubular spout,
B-0199-01
chrome plated metal handles
B-0199-29 B-0199-01-WS
Standard
N/A
Optional Outlets (Series 1 / VR Series 6)
4" Wrist Action (Standard)
B-0199-01-N035
N/A
Lever
B-0199-01-F10
4-Arm
N/A
B-0199-06-N035
(VR Laminar)
N/A
0.5 GPM non-aerated vandal resistant flow device,
B-0199-21
Optional Handles
N/A
B-0199-06
•
resistant flow device, compression cartridges, 4” wrist action handles and 1/2” NPSM male inlets with compression nuts. Certified to ASME
1/2” NPSM male inlets with coupling nuts
•
4” centerset deck mount lavatory mixing faucet with polish chrome plated brass body, swivel gooseneck, 0.5 GPM non-aerated vandal
•
•
Quarter-turn Eterna compression cartridges
A112.18.1/CSA B125.1, NSF 61-Section 9 and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
Series 6 (B-0199-06-N05)
B-0199-01-N05
4” wrist action handles w/ color coded indexes
B-0199-29VR
4” centerset deck mount•
4 3/8” swivel gooseneck•
Non-Aerated
(Laminar)Aerated
N/A
GPM
0.35
0.5
1.0
1.5
2.2
