Specification Sheet

3 3/4"
96mm
1 9/16"
40mm
Rough-In Requirement:
(2) Ø 1 1/8" [29mm] Mounting Holes
Contractor_______________________________________
Date:
Product Specifications:
Scale:
Model No.
Item No.
B-0894
T&S BRASS AND BRONZE WORKS, INC.
KJG
4" Centerset Deck Mount Mixing Faucet, Eterna Cartridges, 4" Wrist Action
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
Handles, Drip Proof Spray Face Outlet & 1/2" NPSM Male Inlets w/
Travelers Rest, SC 29690
08/14/14
Coupling Nuts
JRM
2 Saddleback Cove / P.O. Box 1088
Sheet:
of
12
1:4
Architect/Engineer_________________________________
Checked:
Drawn:
__________________________Date_________
Approved: JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
1 7/8"
48mm
12"
305mm
Eterna Cartridges &
w/ Color Coded Indexes
4" Wrist Action Handles
1/2" NPSM
Male Inlets w/
Coupling Nuts
Mounting
Surface
Thickness
Maximum
19mm
126mm
4 15/16"
102mm
4"
3/4"
5 7/8"
149mm
Drip Proof Spray
Face Outlet
2 11/16"
68mm
