Specification Sheet

ManualsBrandsT and S Brass ManualsShop AllT and S Brass 1.42 GPM Spray Valve with 72" Flexible Stainless Steel Hose and Adapter

77"

1957mm

Hold Down Ring

& Washer

(Included)

Contractor_______________________________________

__________________________Date_________

Product Specifications:

Scale:

Model No.

Item No.

T&S BRASS AND BRONZE WORKS, INC.

05/26/16JRM

B-0954

Model Specified_____________________ Quantity______

Travelers Rest, SC 29690

Date:

1.42 GPM Spray Valve w/ 72" Flexible Stainless Steel Hose & Adapter

Customer/Wholesaler______________________________

2 Saddleback Cove / P.O. Box 1088

1Sheet:

Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com

1:4

Architect/Engineer_________________________________

Checked:

Drawn: Approved:

JBC

JHB

This Space for Architect/Engineer Approval

Job Name

Product Compliance:

ASME A112.18.1 / CSA B125.1

NSF 61 - Section 9

NSF 372 (Low Lead Content)

EPAct 2005 (PRSV)

B-0107-035

1.42 GPM

Male Adapter

1/2" NPT

Spray Valve

72" Flexible

Stainless

Steel Hose

71 7/16"

1814mm

77"

1957mm

Summary of content (2 pages)

PAGE 1
Model No. T&S BRASS AND BRONZE WORKS, INC. 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 B-0954 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.
PAGE 2
Model No. T&S BRASS AND BRONZE WORKS, INC. B-0954 2 Saddleback Cove / P.O. Box 1088 Travelers Rest, SC 29690 Item No. Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com ITEM NO. 1 2 3 4 5 1 2 SALES NO. B-0107-035 1.42 GPM Angled Spray Valve 010476-45 #27 Washer B-0072-H Barbed Insert 000907-45 Spray Valve Hold Down Ring 055A Adapter, 1/2 NPT Male 3 5 Product Compliance: 1.
