Specification Sheet

Ø 2"
51mm
Repair Kit For This
Model is Available
as B-0963-RK
1/2" NPT
Female Inlet
5 11/16"
145mm
4 3/16"
106mm
Bleeder
Field
Screw
Position (As Shown)
Test
Cock
Breaker in Upright
Always Install Vacuum
(2) Quarter-Turn
Shutoff Valve
1/2" NPT
Female Outlet
3 3/8"
86mm
__________________________Date_________
Product Specifications:
Scale:
Model No.
04/12/16JRM
T&S BRASS AND BRONZE WORKS, INC.
Item No.
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
Screw,
Travelers Rest, SC 29690
Date:
Test Cock & 1/2" NPT Female Inlet & Outlet
B-0963
Contractor_______________________________________
Continuous Pressure Vacuum Breaker, 1/4 Turn Ball Valves, Bleeder
Approved: 1
of
2 Saddleback Cove / P.O. Box 1088
Architect/Engineer_________________________________
Checked:
Drawn:
JBC
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
Sheet: 1
1:2
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ASSE 1056 (VB)
