Specification Sheet

7"
178mm
Quick Disconnect Socket
3/4-14 UN
Male Inlet
Self-Closing
Cartridge
3 7/16"
88mm
Date: 1:2
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
07/30/14JRM
B-1420
Self-Closing Spray Valve w/ Quick Disconnect Socket & 3/4-14 UN Male Inlet
2 Saddleback Cove / P.O. Box 1088
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
DHL
Approved:Drawn:
Checked:
Travelers Rest, SC 29690
of
2
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
