Specification Sheet

LOW
LEAD
COMPLIANT
11 9/16"
294mm
14 1/16"
357mm
41 1/8"
1045mm
12 5/8"
321mm
12 1/2"
317mm
3 11/16"
94mm
12"
305mm
Variations Specified__________________________
Model Specified________________Quantity_______
Date______________________________________
Pre-Rinse Unit
Architect/Engineering Specifications:
02/28/18
Three Year (Limited)
Job Name__________________________________
Add-On Faucet: 9.73 GPM @ 60 psi
Spray Valve: 1.42 GPM @ 60 psi
Travelers Rest, SC 29690
•
• EPAct 2005 (PRSV)
• NSF 372 (Low Lead Content)
Ph 800-423-0150
•
2 Saddleback Cove
Simi Valley, CA
•
•
Fax [phone]• Ph 800-476-4103
Pre-Rinse Units
Date:
• NSF 61 - Section 9
Features & Benefits:
www.tsbrass.com
B-2278-01
T&S BRASS AND BRONZE WORKS, INC.
•
Product Compliance:
ASME A112.18.1 / CSA B125.1
CSA B64.8 (VB)
•
•
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Flow Rate: •
Warranty:
TAG:
B-0199-01-F10
B-0199-01-WS
GPM
Material: Polished chrome plated brass body, tubular nozzle, add-on faucet•
body, riser & spray valve body, chrome plated vacuum breaker, stainless
bracket, spray valve holder and overhead spring. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9, NSF 372 and CSA B64.8. EPAct
1/2” NPT supply nipple kit
GPM spray valve, compression cartridges with spring checks, lever handles, 1/2" NPT female inlets, 1/2” NPT supply nipple kit, 6” adjustable wall
B-0199-06-F10
Lever (Standard)
Optional Handles
B-0199-06
4" Wrist Action
B-0108 (1.07 GPM)
B-0108-C (0.65 GPM)
B-0107-C (0.65 GPM)
B-0107-J (1.07 GPM)
8” wall mount mixing faucet with polished chrome plated brass body, continuous pressure vacuum breaker, add-on faucet with compression
•
•
cartridge and lever handle, 12” swing nozzle with stream regulator outlet, 18” riser, 44” flexible stainless steel hose with heat resistant handle, 1.42
6” adjustable wall bracket
Adjustable centers from 7 3/4" to 8 1/4“
VR Aerated
1.0
B-0199-01
steel hose and chrome plated metal handles
4-Arm
1.5
•
2.2
B-0199-06-WS
2005 compliant.
Optional Add-On Faucet Outlets (Series 1 / VR Series 6)
•
1/2" NPT female eccentric inlets with Ø 2" flanges
8” wall mount mixing faucet w/ polished chrome plated brass body•
EasyInstall riser for quick installation•
Continuous pressure vacuum breaker•
Add-on faucet w/ polished chrome plated brass body•
12” swing nozzle w/ stream regulator outlet, Series 1•
18” riser•
44” flexible stainless steel hose with heat resistant gray handle and •
hold down ring
1.42 GPM spray valve•
Quarter-turn Eterna compression cartridges w/ spring checks to prevent cross•
flow of water
Lever handles w/ color coded indexes•
Optional Pre-Rinse Spray Valves
B-0107 (1.42 GPM) (Standard)
Aerated
Optional Cartridges With Checks
Quarter-Turn Cerama w/ Check Valve
Quarter-Turn Eterna w/ Spring Check (Standard)
2 3/8"
61mm
