Specification Sheet

10"
254mm
3 11/16"
94mm
203mm
8"
3 11/16"
93mm
12 5/8"
321mm
Contractor_______________________________________
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
01/22/18JRM
B-2429-CR
2
8" Wall Mount Base Mixing Faucet, Quarter-Turn Cerama Cartridges w/ Check
Customer/Wholesaler______________________________
Model Specified_____________________ Quantity______
Valves, Lever Handles, 10" Swing Nozzle w/ Stream Regulator Outlet & 1/2"
Travelers Rest, SC 29690
Date:
NPT Female Inlets
2 Saddleback Cove / P.O. Box 1088
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
1:6
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
MRC
JHB
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
Mounting Surface
2"
[51mm]
Flanges w/
1/2" NPT
Female Inlets
2 3/8"
61mm
6 7/8"
174mm
Color Coded Indexes
Lock Washer (Included).
w/ Check Valves &
Quarter-Turn Cerama Cartridges
Lever Handles w/
061X
10" Swing Nozzle w/
Stream Regulator Outlet.
Converts to Rigid w/
014200-45
Swivel Joint
