Specification Sheet

3 1/2"
89mm
& Threaded
Locking Rod
Brass Lock Nut
Temperature
Index
Mounting Surface
2 1/8"
54mm
Flange
Hot Cold
1 1/2" [38mm] Mounting Hole
Rough-In Requirement:
Architect/Engineer_________________________________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
09/19/14JRM
B-2740
1:4
Single Lever Remote On/Off Control Base Faucet, Ceramic Cartridge
Travelers Rest, SC 29690
2
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
DHL
Approved:
Date:
& (2) 16" Flexible Stainless Steel Supply Hoses
2 Saddleback Cove / P.O. Box 1088
Checked:
Drawn:
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
ANSI A117.1 (ADA)
13" Flexible Stainless Steel
Outlet Hose w/ 1/2" NPSM
Female Coupling
(2) 16" Flexible
Stainless Steel Supply
Hoses w/ 3/8" Female
Compression Fittings
"OFF"
99mm
3 15/16"
"ON"
Full
5 3/16"
132mm
1"
26mm
Maximum
Thickness
