Specification Sheet

19 1/4"
489mm
5 9/16"
141mm
4 15/16"
126mm
Variations Specified__________________________
One Year (Limited)
Medical and Lavatory Faucets
Concealed Widespread Lavatory Faucet
Architect/Engineering Specifications:
04/12/16
Model Specified________________Quantity_______
Job Name__________________________________
• Flow Rate: 8.22 GPM @ 60 psi
• Ph 800-476-4103
• NSF 61 - Section 9
Ph 800-423-0150
•
Travelers Rest, SC 29690
Simi Valley, CA
•
•
Fax [phone]
Date______________________________________
Date:
• ASME A112.18.1 / CSA B125.1
•
Product Compliance:
•
www.tsbrass.com
B-2865-05
T&S BRASS AND BRONZE WORKS, INC.
ANSI A117.1 (ADA)
Features & Benefits:
•
NSF 372 (Low Lead Content)
• 2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Warranty:
TAG:
4 1/16"
104mm
10 5/8"
270mm
VR Aerated
B-0199-07-WS
B-0199-07-F10
N/A
N/A
B-0199-02-F10
B-0199-02-WS
Aerated
N/A
N/A
B-0199-02
B-0199-07-N05
B-0199-02-N035
Adjustable concealed deck mount mixing faucet with forged brass body, rigid gooseneck with rosespray outlet, compression cartridges,
Wrist Action Metering
B-0199-07
N/A
N/A
B125.1, NSF 61-Section 9 and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
N/A
4” wrist action handles, chrome plated escutcheons and 1/2" NPSM male inlets with coupling nuts. Certified to ASME A112.18.1/CSA
B-0199-07-N035
•
4” wrist action handles w/ color coded indexes
Non-Aerated
Adjustable inlet from 6" to 24"
•
•
1/2" NPSM male inlets w/ coupling nuts
Rosespray outlet, Series 2
•
Quarter-Turn Eterna
Push Button Metering
•
Pivot Action Metering
Material: Forged brass body, chrome plated metal
Eterna compression cartridges
Optional Outlets (Series 2 / VR Series 7)
N/A
N/A
•
(Laminar)
handles & polished chrome plated brass escutcheons
N/A
B-0199-02-N05
and tubular spout
Eterna (Standard)
2.2
1.5
1.0
0.35
GPM
0.5
Adjustable concealed deck mount mixing faucet •
w/ forged brass body
5 9/16" rigid gooseneck •
Optional Cartridges
Quarter-Turn Cerama
VR Non-Aerated
(VR Laminar)
Optional Handles
4" Wrist Action (Standard)
Lever
4-Arm
