Specification Sheet

LOW
LEAD
COMPLIANT
16"
406mm
158mm
6 1/4"
5 3/4"
145mm
•
F
•
Medical and Lavatory Faucets
Concealed Widespread Lavatory Faucet
Architect/Engineering Specifications:
ASME A112.18.1 / CSA B125.1•
Flow Rate: 2.2 GPM @ 60 psi •
Ph 800-476-4103 •
NSF 61 - Section 9•
Features & Benefits:
•
NSF 372 (Low Lead Content)
Product Compliance:
•
Job Name__________________________________
Model Specified________________Quantity_______
Fax [phone]
03/07/17
•
Date______________________________________
Variations Specified__________________________
•
Ph 800-423-0150
•
www.tsbrass.com
B-2866-CR
•
T&S BRASS AND BRONZE WORKS, INC.
ANSI A117.1 (ADA)
Simi Valley, CA
Date:
Travelers Rest, SC 29690 • 2 Saddleback Cove
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 180
Warranty:
One Year (Limited)
Cerama: Lifetime (Limited)
TAG:
(VR Laminar)
B-0199-06-F10
VR Aerated
N/A
B-0199-06-F12
B-0199-06-N035
B-0199-29VR
B-0199-21-VRF
B-0199-06-LF12 B-0199-01-LF12
•
brass tubular spout and chrome plated metal handles
N/A
Material: Forged brass body, polished chrome plated
N/A B-0199-06-N05
VR Non-Aerated
B-0199-06
B-0199-01-N05
B-0199-21
N/A
N/A
B-0199-06-WS
B-0199-01-N035
B-0199-01-F10
B125.1, NSF 61-Section 9 and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.
Optional Handles
action handles, polished chrome plated escutcheons and 1/2" NPSM male inlets with coupling nuts. Certified to ASME A112.18.1/CSA
Standard
B-0199-01-F12
•
•
B-0199-29
8" concealed deck mount mixing faucet with forged brass body, swivel gooseneck with 2.2 GPM aerator, ceramic cartridges, 4” wrist
•
B-0199-01-WS
1/2" NPSM male inlets w/ coupling nuts
4" wrist action handles w/ color coded indexes
4-Arm
2.2 GPM aerator, Series 1 (B-0199-01)
Lever
4" Wrist Action (Standard)
•
Quarter-turn Cerama cartridges
•
convert swivel gooseneck to rigid
Push Button Metering
Pivot Action Metering
Optional Cartridges
Eterna
Quarter-Turn Eterna
5 3/4" swivel gooseneck w/ swivel-to-rigid washer to
Quarter-Turn Cerama (Standard)
Wrist Action Metering
Optional Outlets (Series 1 / VR Series 6)
8" EasyInstall concealed deck mount mixing faucet •
w/ forged brass body
Non-Aerated
(Laminar)
Aerated
N/A
GPM
0.35
0.5
1.0
1.2
1.5
2.2
10 11/16"
271mm
1 1/4"
32mm
Maximum
Thickness
