Specification Sheet

Max Thickness
1-1/4"
[32mm]
6 1/8"
155mm
10 11/16"
271mm
5 3/4"
145mm
Mounting
Flange
Surface
Swivel Deck
1" [25mm] for Center Shank
Rough-In Requirement:
1-1/2" [38mm] for Hot/Cold Side
& VR Screws
w/ Color Coded Indexes
& 4" Wrist Action Handles
1/4 Turn Eterna Cartridges
2"
[51mm]
1/2" NPSM
Coupling Nuts
8"
203mm
Swivel Gooseneck
w/ B-0199-21 VRF
2.2 GPM VR Laminar Device
(Optional Swivel/Rigid Washer
Included)
2-1/4"
[57mm]
Escutcheons
16"
406mm
of
2
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
06/21/12
DMH
B-2866-QT-21VR
1Sheet:
EasyInstall Faucet w/ 4" Wrist Action Handles w/ VR Screws,
2 Saddleback Cove / P.O. Box 1088
1/4 Turn Eterna Cartridges, 8" Inlet Centers & Swivel
Travelers Rest, SC 29690
Date:
Gooseneck w/ 2.2 GPM VR Laminar Flow Device
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
JHB
JRM
Approved
Drawn
1:4
Architect/Engineer_________________________________
Checked
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
