Specification Sheet
6
3
4 5
11
7
8
9
1
10
2
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: 864-834-3518 • www.tsbrass.com
B-7132-08M
02/28/18
Travelers Rest, SC 29690
NTS
2 Saddleback Cove / P.O. Box 1088
KJG
EPAct 2005 Non-Compliant (PRSV)
2
of
2Sheet:JHB
JRM
Approved:Drawn:
Checked: Date:
3/8" x 35 Ft. Open Stainless Steel Reel w/ 1.07 GPM Spray Valve & Swivel
Product Compliance:
NSF 61 Exempt (Non-Potable)
Product Specifications:
ITEM
NO.
SALES NO. DESCRIPTION
1 B-0108 1.07 GPM B-0108 Spray Valve
2 016154-25 B-0108 3/8" NPT Hose Adapter
3 014949-45 Hose Stop Repair Kit
4 014941-45 3/8" x 35' Hose Replacement Kit
5 014946-45 3/8" Swivel Repair Kit
6 014948-45 O-Ring Replacement Kit
7 014933-45 Small SS Spring Assembly
8 014938-45 Roller Assembly Repair Kit
9 014940-45 Ratchet Repair Kit
10 010476-45 #27 Washer
11 019652-40 3/8" NPT Live Swivel
