Specification Sheet

4 1/8"
104mm
5 1/2"
140mm
B-0199-02-N05
N/A
GPM
N/A
•
Material: Polished chrome plated brass body and tubular spout
N/A
•
B-0199-02-WS
0.5
B-0199-02-N035
1.0 B-0199-02-F10
(Laminar)
Optional Outlets (Series 2 / VR Series 7)
Low battery LED indicator light
NSF 61-Section 9, NSF 372 and UL 1951. Meets ADA ANSI/ICC A117.1 requirements.
connections
2.2
•
Mechanical temperature mixing valve w/ check valves
1.5
Two flexible stainless steel supply hoses w/ 3/8" compression
Aerated
B-0199-02 N/A
•
stainless steel supply hoses with 3/8" compression connections. Certified to ASME A112.18.1/CSA B125.1,
aerator, AC/DC control module with internal flow control setting switches, temperature control mixing valve with check valves and 18" flexible
N/A
•
0.35
Single hole wall mount electronic sensor faucet with polished chrome plated brass body and 4 1/8" rigid gooseneck, 2.2 GPM vandal resistant
Single hole wall mount faucet w/ polished chrome plated brass body•
4 1/8" rigid gooseneck •
2.2 GPM vandal resistant aerator, Series 2 (B-0199-07)•
Water resistant control module w/ internal flow control switches for •
adjusting auto time out & shut off delay settings
Optional auto flush feature flows water for 30 seconds after every •
12 inactive hours
Plug in AC transformer or (4) AA battery (DC) power options
Non-Aerated
VR Aerated
N/A
N/A
B-0199-07-F10
B-0199-07-WS
Standard
•
•
Model Specified________________Quantity_______
Variations Specified__________________________
Three Year (Limited)
Electronic Faucets
•
UL 1951
•
Simi Valley, CA
•
•
•
Travelers Rest, SC 29690
EC-3101-BA
Ph 800-476-4103
Job Name__________________________________
ASME A112.18.1 / CSA B125.1
ANSI A117.1 (ADA)
www.tsbrass.com
• NSF 372 (Low Lead Content)
• NSF 61 - Section 9
T&S BRASS AND BRONZE WORKS, INC.
2 Saddleback Cove
Electronic Sensor Faucet
• Fax [phone]
Date:
Product Compliance:
Ph 800-423-0150
•
08/26/16
Architect/Engineering Specifications:
@ 15 sec = .55 gal
Date______________________________________
Features & Benefits:
•
Performance Data:
Pressure: 20 - 125 psi •
Temperature: 40
F - 140 F•
Flow Rate: 2.2 GPM @ 60 psi •
Water Consumption: @ 10 sec = .37 gal
Warranty:
TAG:
5/16"
8mm
Thickness
Maximum
1 15/16"
49mm
10 15/16"
278mm
13/16"
21mm
2 1/4"
57mm
