Specification Sheet

(1) 90° Elbow
Installation Kit: Restraining
Cable, Street El, Ball Valve
"L" = Length 1/2" NPT
12" HG-2C-12K
24" HG-2C-24K
36" HG-2C-36K
48" HG-2C-48K
60" HG-2C-60K
72" HG-2C-72K
"L" = Length 3/4" NPT
12" HG-2D-12K
24" HG-2D-24K
36" HG-2D-36K
48" HG-2D-48K
60" HG-2D-60K
72" HG-2D-72K
"L" = Length 1" NPT
12" HG-2E-12K
24" HG-2E-24K
36" HG-2E-36K
48" HG-2E-48K
60" HG-2E-60K
72" HG-2E-72K
"L" = Length 1 1/4" NPT
12" HG-2F-12K
24" HG-2F-24K
36" HG-2F-36K
48" HG-2F-48K
60" HG-2F-60K
72" HG-2F-72K
2
HG - 2 - K
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
10/09/15JRM
HG-2-K Series
D
Customer/Wholesaler______________________________
Safe-T-Link Gas Appliance Connector: Coated Hose w/ NPT Male Ends,
Travelers Rest, SC 29690
Date:
90° Elbow & Installation Kit
36
Ex: HG - -
Gas Hose, 3/4" NPT Male Ends, 36" Length, (1) 90° Elbow, (1) Installation Kit
K
NFPA 54
Model Specified_____________________ Quantity______
1:1
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
KJG
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
Sheet: 1
of
2 Saddleback Cove / P.O. Box 1088
Contractor_______________________________________
1
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Product Compliance:
ANSI Z21.69 / CSA 6.16
NSF 2
HG-2-K Series Product Configurator:
Coated Gas Connector
w/ NPT Male Ends
