Specification Sheet

2 Saddleback Cove / P.O. Box 1088
Contractor_______________________________________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
12/21/15JRM
MV-2516-24
1:4
1
Stainless Steel Water Gun w/ Blue Rubber Cover, Rear Style Trigger &
Travelers Rest, SC 29690
Date:
Ø 5/16" Flow Orifice
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
KJG
Approved:
Architect/Engineer_________________________________
Checked:
Drawn:
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Product Compliance:
NSF 61 Exempt (Non-Potable)
Rear Style Trigger
w/ Blue Rubber Cover
Hold Down Clip
Blue Rubber Cover
Valve Body
Stainless Steel
Retractable Trigger
Blue Rubber Cover
5 9/16"
141mm
6 3/4"
171mm
Ø 5/16"
Flow Orifice
Ø 2 5/16"
[Ø 59mm]
1/2" NPT Female Inlet
T&S Logo on Top
