Specification Sheet

7 7/16"
189mm
Approved:
Contractor_______________________________________
Product Specifications:
Scale:
Model No.
01/18/16JRM
MV-2522-24
T&S BRASS AND BRONZE WORKS, INC.
Stainless Steel Water Gun w/ Blue Rubber Cover, Front Style Trigger,
Travelers Rest, SC 29690
Date:
Ø 5/16" Flow Orifice & 1/2" NPT Female Inlet
Item No.
1
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
2 Saddleback Cove / P.O. Box 1088
Architect/Engineer_________________________________
Checked:
Drawn:
JBC
JHB
1:4
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Product Compliance:
NSF 61 Exempt (Non-Potable)
Hold Down Clip
w/ Blue Rubber Cover
Front Trigger Style
Valve Body
Stainless Steel
Blue Rubber Cover
Blue Rubber Cover
Retractable Trigger
Trigger Guard
5 9/16"
141mm
Ø 5/16"
Flow Orifice
Ø 2 5/16"
[Ø 59mm]
1/2" NPT Female Inlet
T&S Logo on Top
