Specification Sheet

13 3/4"
349mm
269mm
10 9/16"
2 5/16"
59mm
8"
204mm
Rigid to Swivel
Adapter
& Lever Handle
Cerama Cartridge
Add-On Faucet
w/ Quarter-Turn
Mounting
Surface
2 3/8"
61mm
Female Inlets
1/2" NPT
Lock Nut
Steel Hose
& Bushing
Spray Valve (Blue)
Swivel
Adapter
B-0970-FE
3/8" NPT
Vacuum Breaker
96" Flexible Stainless
EB-0107-035
High Flow Angled
Adjustable From
7 3/4" to 8 1/4"
[197mm to 210mm]
90
EasyInstall
Ø 2" [51mm]
Flanges w/
B-0166
Hanger Hook
93mm
3 11/16"
391mm
15 3/8"
8"
203mm
Color Coded Indexes
Lever Handles w/
w/ Check Valves &
Quarter-Turn
Cerama Cartridges
8" Wall Mount Mixing Faucet, Quarter-Turn Cerama Cartridges w/ Check
__________________________Date_________
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
02/17/17JRM
P3-8WESV-08M-CR
Valves, Lever Handles, Add-On Faucet, 8" Swing Nozzle w/ Stream
2 Saddleback Cove / P.O. Box 1088
Contractor_______________________________________
Customer/Wholesaler______________________________
Regulator Outlet, Vacuum Breaker, High Flow Angled Spray Valve (Blue), 96"
Travelers Rest, SC 29690
Date:
Flexible Stainless Steel Hose & 1/2" NPT Female Inlets
Model Specified_____________________ Quantity______
2
of
1Sheet:
1:8
Architect/Engineer_________________________________
Checked:
Drawn: Approved:
DMH
JHB
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
This Space for Architect/Engineer Approval
Job Name
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 Exempt (Non-Potable)
EPAct 2005 Non-Compliant (PRSV)
CSA B64.8 (VB)
060X
8" Swing Nozzle
w/ Stream
Regulator Outlet
12 5/8"
321mm
