Specification

Hydronic Accessories

Taco’s cartridge style pressure reducing valve sets a new standard for performance

and serviceability. All the parts are contained in a one piece cartridge which can be

easily removed and serviced without reducing the system pressure. A fast-ll mode

that automatically returns to the normal mode when the set pressure is reached and

delivers increased ow to speed system ll times. Its unique dial-in pressure setting

allows for easy adjustment throughout the 10-50 psi range, without the need for an

external gauge. Now available with 1/2” union press connection.

Cartridge Style Pressure Reducing Valve

Convenient one-piece cartridge

Supersedes: 09/14/12

Effective Date: 07/06/17

Printed in USA

PAGE 1
Hydronic Accessories Cartridge Style Pressure Reducing Valve Taco’s cartridge style pressure reducing valve sets a new standard for performance and serviceability. All the parts are contained in a one piece cartridge which can be easily removed and serviced without reducing the system pressure. A fast-fill mode that automatically returns to the normal mode when the set pressure is reached and delivers increased flow to speed system fill times.
PAGE 2
Submittal Data Information Cartridge Style Pressure Reducing Valve Features Automatic Pressure Reset from Fast Fill Easy External Dial-up Pressure Setting Set Pressure Indicator Simple serviceability with the unique one piece cartridge Internal check allows the cartridge to be replaced without draining the system Integral Strainer ASSE 1003 Product Specifications Max. Inlet Pressure..........250 psi Adjustment Range.........10 – 50 psi Max. Temp...........................
