Stay frosty with the Ear Force X12 Arctic Edition gaming headset with crystal-clear chat on Xbox LIVE® or PC and amplified audio for the ultimate audio experience.
Table of Contents Package Contents P4 Using the X12 In-Line Amplifier P5 Xbox 360® Setup P6 PC Setup P11 Troubleshooting P12 Specifications P13 Compliance / Conformity P14
Package Contents B A Ear Force X12 Headset with In-line Amplifier RCA Splitter Cable C D Xbox 360 Chat Cable Turtle Beach Sticker Go to Table of Contents 4
Using the X12 In-Line Amplifier Chat Volume Control Game Volume Control Mic Mute Indicator LED Xbox 360 Chat Jack Green = Mic On Red = Mic Muted Bass Boost Control Mic Mute Switch Chat Volume Control Controls the level of incoming chat audio from your Xbox 360. Game Volume Control Controls the level of game audio from your Xbox 360. On the PC this will act as a master volume (Game+Chat). Bass Boost Control Adjusts the Bass Boost intensity. Turn this up for a more powerful bass response.
Xbox 360 Slim HDMI Setup The Ear Force X12 Arctic Edition can be set up a variety of ways to match different Xbox 360 Console Versions and A/V Connections. Check the following pages for the set-up that most closely resembles your home gaming system. Xbox 360® Slim HDMI Setup/Configuration Xbox 360® Slim – HDMI HDMI E HDMI Xbox 360® Audio Adapter* A green pink (not used) USB USB B D For best Xbox chat performance, use with official Microsoft Xbox 360 products.
Xbox 360® Slim RCA Setup green pink (not used) Go to Table of Contents 7
Xbox 360 E HDMI Setup pink (not used) green Go to Table of Contents 8
Xbox 360 E RCA Setup Xbox 360 ® E - RCA Setup white white red red E yellow yellow green pink (not used) A AV USB USB B D Go to Table of Contents 9
Xbox 360 Chat Setup Voice Voice Volume 10 Game Volume 10 Mute Kinect Voice Output Play Through Headset Play Through Speakers Play Through Both Select Settings > Preferences > Voice • Set Voice Volume = 10 • Set Game Volume = 10 • Set Voice Output = Play Through Headset Go to Table of Contents 10
PC Setup The Ear Force X12 Arctic Edition is compatible with Windows PCs that have separate Green (Audio) and Pink (Microphone) headset connections. The USB is required for power only.
Troubleshooting My mic doesn’t work (other players can’t hear me). - Connect the USB plug from the X12 to a USB port on your console. - Make sure the X12 amp box LED is lit *green*. If it’s lit red, set the Mute switch to “On” to make the LED green. - Put on the headset and speak into the mic. - You should hear your own voice in the headset. If not, then please contact tech support. I don’t hear game audio in either/both speakers.
Specifications · Speaker Dimensions: 50mm · Speaker Core: Neodymium Magnets · Speaker Impedance: 32Ω · Speaker Frequency Response: 20Hz – 20KHz 120dB @ 1KHz · Headphone Amplifier: Stereo · Output Power: 35mW/Ch · Earcup Style: Around Ear · Cushion Material: Foam · Earcushion Material: Fabric · Headband Design: Plastic · Headband Cushion: Foam · Headband Material: Fabric/Leather · Acoustic Design: Closed · Acoustic Frequency Response: 20Hz – 20KHz · Total Harmonic Distortion: < 1% · Bass Boost: Variable up
Regulatory Compliance Statements for the X12 Arctic Models Federal Communications Commission (FCC) Compliance Notices Class B Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Declaration of Conformity Heading Marking by this symbol: indicates compliance with the Essential Requirements of the EMC Directive of the European Union (2004/108/EC). This equipment meets the following conformance standards: Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 (T-Mark License) Also Licensed for Standards: IEC 60950-1: 2005 (2nd Edition) + Am 1: 2009 (CB Scheme Report/Certificate), UL 60950-1: 2007 R12.11 (NRTL License), CAN/CSA-C22.2 No.
