User's Manual

Specifications
IDEAL LIFE Gluco-Manager™
Model: GMM 0001 IDEAL LIFE Gluco-Manager™
Display: LCD Digital Display
Power Source: Two 1.5V AAA alkaline batteries
Battery Life: Over 200 determinants
Operating Temperature/Humidity: 50°F to 104°F (10°C to 40°C), below 85% R.H. (non-condensing)
Meter Storage Temperature/Humidity: -4°F to 140°F (-20°C to 60°C), below 95% R.H.
Weight: 103.5 g
Dimension: 97 mm (l) x 77.7 mm (w) x 24.8 (h)
Auto Electrode Inserting Detection YES
Auto Sample Loading Detection YES
Sleeping Mode Power Consumption Less than 500uA
Auto Shut Off After 2 minutes without action
Measurement Units mg/dL or mmol/L
Note: these specifications, to improve performance, are subject to change without notice.
IDEAL LIFE Pod™
Model: ILP 0001 IDEAL LIFE Pod™
Display: 3 LED’s
Power Source: AC adapter
Operating Temperature/Humidity: 50°F to 104°F (10°C to 40°C)/Below 85% relative humidity
Storage Temperature/Humidity 23°F to 122°F (-5°C to 50°C)/Below 90% relative humidity
Console Weight: Approx. 142 g without batteries
Outer Dimensions: Approx. 120 mm Width x 105 mm Depth x 30 mm Height
Note: These specifications are subject to change without notice.
Specifications
IDEAL LIFE Gluco-Manager™
32
