B475 USER MANUAL
CONTENTS 1. Introduction .......................................................................................................... 5 2. Unpacking............................................................................................................ 5 3. Connectors/Cabling ............................................................................................. 5 4. Polarity Checking ................................................................................................. 6 5.
1. Introduction Thank you for purchasing Tannoy B475. The Tannoy B475 is an 18” direct radiating bass loudspeaker system, designed for high definition sound reinforcement at low and ultra-low frequencies. It will extend the power bandwidth of Tannoy i/T range mid/high sound reinforcement systems to below 30Hz, making it ideal for effects in club, theatre and concert sound applications, with ultra-low frequency enhancement and increased system headroom.
CABLE RUN (m) C.S.A. OF EACH CONDUCTOR (mm) CABLE RESISTANCE Ω % POWER LOSS INTO 8Ω Ω LOAD % POWER LOSS INTO 4Ω Ω LOAD 10 2.5 4.0 6.0 2.5 4.0 6.0 2.5 4.0 6.0 2.5 4.0 6.0 0.14 0.09 0.06 0.35 0.22 0.14 0.69 0.43 0.29 1.38 0.86 0.58 1.7 1.1 0.73 4.3 2.7 1.8 8.6 5.4 3.6 17.0 11.0 7.2 3.5 2.2 1.5 8.6 5.4 3.6 17.0 11.0 7.2 35.0 22.0 14.0 25 50 100 4. Polarity Checking It is most important to check the polarity of the wiring.
6. Crossovers For optimal performance the B475 has been designed to operate with Tannoy Install or Transportable series, e.g. i12/T12, i15 and T300, where overall system control is achieved by utilising the TDX2 system controller. The TDX2 has been factory preset to provide the recommended cross-over points, delays and overall system balance. Please refer to the TDX2 manual for operation. Alternatively, Tannoy TX1, TX2 and TX3 system controllers can be used.
9. Positioning When a bass loudspeaker is used in an environment with boundary surfaces, its placement affects its frequency response. When such effects are properly understood, they can be used to great effect in producing the desired sound quality without the aid of additional amplification. Consider Figure 9a in the diagram below, here we see a loudspeaker in free field or anechoic conditions. We measure its sound pressure level at a distance D, and refer to this as our reference level, or 0 dB SPL.
10.
11. Technical Specifications Frequency response (1) +/- 3dB 28Hz - 240Hz Recommended Amplifier Power 400 - 800 Watt / 8Ω Power Handling Average (2) 300 Watt Programme 600 Watt Sensitivity (1) 2.83 volt @ 1m 98dB 101dB (half space) Maximum SPL (3) @ 1m Average 123dB Peak 129dB Impedance Nominal Minimum 8Ω 7.8Ω Distortion 0.1 Full Power 100 Hz 250 Hz 0.01 Full Power 100 Hz 250 Hz Peak (10ms) 1200 Watt nd 3 Harmonic 0.12% 0.08% nd 3 Harmonic 0.23% 0.29% 2 Harmonic 0.22% 0.
12. B475 Service Parts & Accessories Part Number 7900 0599 7900 0603 Description Driver Kit Type 4505 Recone Kit Type 4505 8001 2190 EBS10 Eye Bolt Set M10 8000 0727 8000 0728 8000 0729 TDX2 Digital loudspeaker management system 60-250V - UK TDX2 Digital loudspeaker management system 60-250V - EUR TDX2 Digital loudspeaker management system 60-250V - USA 13. Warranty No maintenance of the B475 loudspeaker is necessary.
Tannoy Limited, Professional Division, Coatbridge, Strathclyde, ML5 4TF, Scotland. Tel: +44 (0) 1236 420199 Fax +44 (0) 1236 428230 e-mail: prosales@tannoy.com Website: www.tannoy.com Tannoy / TGI North America Inc., 335 Gage Avenue, Suite 1, Kitchener, Ontario, Canada N2M 5E1. Tel: (519) 745-1158 Fax: (519) 745-2364 e-mail: inquiries@tgina.com Website: www.tannoy.com Tannoy Nederland b.v., Anthonetta Kuijlstraat 19, 3066 GS Rotterdam. Tel: (010) 286 0554 Fax: (010) 286 0431 e-mail: info@tannoy.
