O WNE R’S M A N U A L
CONTENTS INTRODUCTION 03 POSITIONING AND FINE TUNING 06 DRIVER TECHNOLOGY 03 GRILLES 06 AMPLIFIER CHOICE 04 CARE OF CABINET 06 CABLE CHOICE 04 REVOLUTION XT HOME THEATRE 5.
INTRODUCTION Thank you for selecting Tannoy loudspeakers developed in the UK by our dedicated team of design engineers. They are the choice of discriminating music lovers the world over. Musical excellence is designed into our loudspeakers from the start. Careful selection of the very best components combined with strict quality control procedures in the production process ensures this level of excellence is maintained.
AMPLIFIER CHOICE Consult the product specification as this clearly shows the acceptable power range for amplifier matching to your speakers. The high peak power handling of Tannoy loudspeakers permits responsible use with more powerful amplifiers - please read the Warranty. As with all loudspeaker systems, the power handling is a function of voice coil thermal capacity.
INSTALLATION To avoid potential damage to your loudspeaker, ensure that the amplifier is switched OFF prior to connecting or disconnecting any cables. Before switching on double check that all connections are secure and that polarity is correct. CONNECTION IN SINGLE WIRE MODE For single wire mode, leave the link plates between the LF and HF terminals in place. (See Fig.
BI-AMPING Bi-Amping extends the principle of bi-wiring one stage further. In this connection option separate power amplifiers are used for bass and treble signals in each loudspeaker. Four mono (or two stereo) amplifiers of the same type are required for a stereo pair of loudspeakers. Ensure that the link plates between the loudspeaker terminals are removed and that correct polarity is maintained throughout.
REVOLUTION XT HOME THEATRE 5.1 - GENERAL INFORMATION Unlike other forms of encoded surround audio, 5.1 offers full bandwidth capability for the surround and centre channels, with the ability to treat the subwoofer as a single discreet channel for special effects playback or, for music applications, as a dedicated low frequency instrument channel. This places new demands on the surround and centre channel loudspeakers in both the mixing environment and the playback environment. The 5.
TECHNICAL SPECIFICATIONS REVOLUTION XT 6 REVOLUTION XT 6F REVOLUTION XT 8F Recommended amplifier power (watt RMS) 25 - 120 25 - 150 25 - 200 Continuous power handling (watt RMS) 60 75 100 Peak power handling (watt) 240 300 400 Sensitivity (2.
TECHNICAL SPECIFICATIONS REVOLUTION XT Mini REVOLUTION XT C Recommended amplifier power (watt RMS) 25 - 100 25 - 120 Continuous power handling (watt RMS) 50 60 Peak power handling (watt) 200 Sensitivity (2.83 volt @ 1 m) 88 dB 89 dB Nominal Impedance (ohm) 8 8 Frequency response (-6 dB) 68 Hz - 52 kHz 62 Hz - 52 kHz Dual Concentric high frequency 20 mm (0.79”) Linear PEI dome with Torus Ogive WaveGuide and Omnimagnet technology 20 mm (0.
SET-UP DIAGRAMS Fig.1 Unpacking Fig.
SET-UP DIAGRAMS Fig.3 Bi-Wire Mode T R TO RIGHT SPEAKER + L + R POWER AMPLIFIER LINKS REMOVED LINKS REMOVED Fig.
SET-UP DIAGRAMS Fig.5 Recommended Positioning - Stereo Pair 0.5 METRES OR MORE 1.5 To 4.5 METRES ONE METRE OR MORE 1 METRE OR MORE Fig.6 Recommended Positioning - Home Cinema 1.5 To 4.5 METRES CENTRE REAR 0.
NOTES REVOLUTION XT MANUAL_013
014_ REVOLUTION XT MANUAL
REVOLUTION XT MANUAL_015
tannoy.com 6481 0673 / 280115 Tannoy Limited - product designed in the United Kingdom. Tannoy adopts a policy of continuous improvement and product specification is subject to change. All other trademarks remain the property of their respective owners.
