ASSEMBLY INSTRUCTIONS CORNER SOFA SET NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS WF198164AAA WF198165AAA WF198164AAC WF198165AAC
N P O K A F B E L C D C C H G M Q J C I C D D D D C C Notice: 1. 50% Tighten before fixing all screws, Allen wrench is recommended instead of an electric drill. 2. Place the item on a flat ground to adjust and make sure it remains stable 3. Tighten up all screws with tools gradually. 4. If the screws are not aligned with holes during assembly, please loosen all the other screws to 50% and continue the assembly process. 5.
Part List A B Back Frame (2pcs) D C Seat Frame (2pcs) E Front Frame (6pcs) G F Big Corner Frame (1pc) H I K L N Q Big corner Pillow (1pc) Corner seat Cushion (1pc) O Back Pillow (2pcs) Ottoman Cushion (1pc) P Table top Frame (1pc) Seat Cushion (2pcs) Ottoman Frame (1pc) M Small Corner Frame (1pc) Corner front Frame (1pc) Corner Seat Frame (1pc) J Side Frame (9pcs) Table Glass (1pc) 3 Small corner Pillow (1pc)
Hardware List 1 2 Bolt M6 x 30 mm 60 pcs + extra 3 pcs 4 3 Bolt M6 x 25 mm 40 pcs + extra 3 pcs 5 Leg Soles (20pcs) Allen key M4 (2 pcs) 4 M6x1 Washers 60 pcs + extra 3 pcs
STEP 2 STEP 1 Connect Back Frame (A) & Seat Frame (B) with Bolt (1) & Washers (3) Connect Part from STEP 1 & Side Frame (C) with Bolt (1) & Washers (3) C C B 1 A 1 1 1 1 1 STEP 3 STEP 4 Connect Part from STEP 3 & Leg Soles (4) with Bolt (2) Connect Part from STEP 2 & Front Frame (D) with Bolt (1) & Washers (3) 2 4 D 1 1 1 1 5
STEP 5 STEP 6 Connect Small Corner Frame (F) & Corner Seat Frame (G) with Bolt (1) & Washers (3) Put on Seat Cushion (K) & Back Pillow (N) to complete Chair F N G K 1 1 STEP 7 STEP 8 Connect Part from STEP 6 & Big corner Frame (E) with Bolt (1) & Washers (3) Connect Part from STEP 7 & Side Frame (C) with Bolt (1) & Washers (3) E 1 1 1 1 1 C 6
STEP 10 STEP 9 Connect Part from STEP 9 & Leg Soles (4) with Bolt (2) Connect Part from STEP 8 & Corner front Frame (H) with Bolt (1) & Washers (3) 2 4 1 1 1 H STEP 11 STEP 12 Connect Ottoman Frame (J) & Front Frame (D) & Side Frame (C) with Bolt (1) & Washers (3) Put on Corner Seat Cushion (L) & Big Corner Pillow (P) & Small Corner Pillow (O) to complete corner Chair C D O 1 P 1 1 L 1 1 J 7
STEP 14 STEP 13 Connect part from STEP 12 & Side Frame (C) & Front Frame (D) with Bolt (1) & Washers (3) Connect Part from STEP 13 & Leg Soles (4) with Bolt (2) 2 D 4 C 1 1 1 1 1 1 1 STEP 15 STEP 16 Put on Ottoman Cushion (M) to complete Ottoman Connect Table top Frame (I) & Front Frame (D) & Side Frame (C) with Bolt (1) & Washers (3) C D M 1 1 1 1 1 I 8
STEP 18 STEP 17 Connect part from STEP 16 & Side Frame (C) & Front Frame (D) with Bolt (1) & Washers (3) Connect Part from STEP 17 & Leg Soles (4) with Bolt (2) 2 D 4 C 1 1 1 1 1 1 1 STEP 19 STEP 20 Put on Table Glass (Q) to complete Table Q FINISH 9
