CGA Fitting Restraint Kit
Installation Instructions
1. Select appropriate restraint for CGA fitting. Restraint washer should fit CGA fitting closely.
2. Place restraint washer over the appropriate CGA fitting.
3. Wrap resistant cable around valve stern.
4. Attach free end of cable with lock as shown above.
5. Push clasp firmly into lock body to secure.
Part Number
Gas Service
XL50-9C50
XL50-9C51
XL50-9C52
Nitrogen or Argon
Oxygen
Carbon-Dioxide or Nitrogen-Oxide
Note: Highlight appropriate row
Taylor-Wharton
4075 Hamilton Blvd.
Theodore, AL 36590
Phone: [phone]
In the US or Candada: (800)TW TANKS (898-
2657)
Fax: [phone]
TW-319
Kits include the following parts:
Vent Valve Liquid Valve Use Valve
Service Kit P/N
V
ent Restraint
P/N
Liquid Restraint P/N Use Restraint P/N
Nitrogen or Argon
XL50-9C50
set
7114-0115 7114-0115 7114-0117
Oxygen
XL50-9C51
set
7114-0116 7114-0116 7114-0116
Carbon Dioxide or
Nitrous Oxide
7114-0116
XL50-9C52
set
7114-0115 7114-0116
